Side Tilt Carriage - Rated by the fork carriage lifting capacity, there are actually four sizings of hook type tine carriages. The hook type blade carriages have been standardized.
The carriage bar spacing utilized for Class 1 is around thirteen inches and the Class 1 carriage is rated to carry cargo as much as 2000lbs. The Class 2 carriage is rated to hold loads up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for cargo up to 15,500 lbs. The carriage bar spacing utilized for this capacity is 25 inches.
The carriages for pin type tines could be different depending on the maker. Pin mounted forks may vary by the amount of offset between the tine eye and the fork. Carriage capacity would be determined by the carriage pin size and by the tine size.
