Forklift Drive Axle

Drive Axle for Forklift - A forklift drive axle is actually a piece of equipment that is elastically connected to a vehicle framework with a lift mast. The lift mast is connected to the drive axle and could be inclined round the axial centerline of the drive axle. This is done by no less than one tilting cylinder. Forward bearing components along with back bearing elements of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the back bearing parts. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is attached to the vehicle frame and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented almost parallel to a plane extending from the axial centerline and to the swiveling axis.

Model H45, H35 and H40 forklifts, that are manufactured by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle framework itself. The drive axle is elastically attached to the frame of the lift truck by numerous various bearings. The drive axle has tubular axle body together with extension arms connected to it and extend rearwards. This particular type of drive axle is elastically affixed to the vehicle framework utilizing rear bearing elements on the extension arms along with forward bearing devices situated on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the lift truck from the other bearing device in its respective pair.

The braking and drive torques of the drive axle on tis particular unit of lift truck are sustained utilizing the extension arms through the back bearing components on the framework. The forces generated by the load being carried and the lift mast are transmitted into the floor or street by the vehicle frame through the front bearing parts of the drive axle. It is vital to be sure the components of the drive axle are constructed in a rigid enough method to maintain stability of the lift truck truck. The bearing elements can minimize slight bumps or road surface irregularities all through travel to a limited extent and provide a bit smoother operation.
