Forklift Starter

Starters for Forklift - The starter motor these days is normally either a series-parallel wound direct current electric motor which consists of a starter solenoid, which is similar to a relay mounted on it, or it can be a permanent-magnet composition. When current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion that is positioned on the driveshaft and meshes the pinion with the starter ring gear which is found on the engine flywheel.

Once the starter motor begins to turn, the solenoid closes the high-current contacts. When the engine has started, the solenoid has a key operated switch that opens the spring assembly to pull the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This permits the pinion to transmit drive in only a single direction. Drive is transmitted in this manner through the pinion to the flywheel ring gear. The pinion remains engaged, for example since the driver did not release the key when the engine starts or if the solenoid remains engaged since there is a short. This causes the pinion to spin separately of its driveshaft.

This aforesaid action stops the engine from driving the starter. This is an important step in view of the fact that this particular kind of back drive will allow the starter to spin so fast that it would fly apart. Unless modifications were done, the sprag clutch arrangement will stop utilizing the starter as a generator if it was employed in the hybrid scheme discussed earlier. Normally a standard starter motor is meant for intermittent use that would stop it being utilized as a generator.

The electrical components are made to be able to function for around thirty seconds to stop overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical parts are meant to save weight and cost. This is the reason the majority of owner's handbooks intended for vehicles recommend the operator to stop for at least ten seconds after each and every ten or fifteen seconds of cranking the engine, whenever trying to start an engine that does not turn over at once.

During the early 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Before that time, a Bendix drive was used. The Bendix system works by placing the starter drive pinion on a helically cut driveshaft. Once the starter motor starts turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear allows the pinion to go beyond the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.

In the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design that was developed and introduced during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism together with a set of flyweights within the body of the drive unit. This was much better for the reason that the typical Bendix drive used to be able to disengage from the ring when the engine fired, though it did not stay functioning.

The drive unit if force forward by inertia on the helical shaft when the starter motor is engaged and starts turning. Then the starter motor becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is attained by the starter motor itself, for instance it is backdriven by the running engine, and after that the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement can be prevented previous to a successful engine start.
