Forklift Throttle Body
Throttle Body for Forklifts - Where fuel injected engines are concerned, the throttle body is the part of the air intake system that regulates the amount of air which flows into the engine. This mechanism works in response to operator accelerator pedal input in the main. Normally, the throttle body is placed between the air filter box and the intake manifold. It is normally connected to or placed next to the mass airflow sensor. The largest component in the throttle body is a butterfly valve called the throttle plate. The throttle plate's main function is in order to regulate air flow.
On the majority of automobiles, the accelerator pedal motion is transferred through the throttle cable, hence activating the throttle linkages works to move the throttle plate. In vehicles with electronic throttle control, otherwise referred to as "drive-by-wire" an electric motor controls the throttle linkages. The accelerator pedal is attached to a sensor and not to the throttle body. This particular sensor sends the pedal position to the ECU or Engine Control Unit. The ECU is responsible for determining the throttle opening based upon accelerator pedal position along with inputs from various engine sensors. The throttle body consists of a throttle position sensor. The throttle cable connects to the black part on the left hand side which is curved in design. The copper coil situated close to this is what returns the throttle body to its idle position as soon as the pedal is released.
The throttle plate revolves within the throttle body each time the driver presses on the accelerator pedal. This opens the throttle passage and allows much more air to be able to flow into the intake manifold. Normally, an airflow sensor measures this adjustment and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors to be able to produce the desired air-fuel ratio. Generally a throttle position sensor or likewise called TPS is fixed to the shaft of the throttle plate to provide the ECU with information on whether the throttle is in the idle position, the wide-open position or also called "WOT" position or somewhere in between these two extremes.
Some throttle bodies can have adjustments and valves so as to regulate the lowest amount of airflow throughout the idle period. Even in units that are not "drive-by-wire" there would often be a small electric motor driven valve, the Idle Air Control Valve or also called IACV which the ECU utilizes in order to regulate the amount of air which could bypass the main throttle opening.
In many vehicles it is common for them to contain one throttle body. To be able to improve throttle response, more than one can be utilized and attached together by linkages. High performance automobiles such as the BMW M1, together with high performance motorcycles such as the Suzuki Hayabusa have a separate throttle body for each cylinder. These models are called ITBs or "individual throttle bodies."
The carburator and the throttle body in a non-injected engine are quite similar. The carburator combines the functionality of both the fuel injectors and the throttle body together. They could control the amount of air flow and combine the air and fuel together. Automobiles that include throttle body injection, that is called TBI by GM and CFI by Ford, situate the fuel injectors within the throttle body. This permits an older engine the opportunity to be converted from carburetor to fuel injection without considerably changing the design of the engine.
