Hydraulic Control Valves for Forklift

Hydraulic Control Valves for Forklift - The job of directional control valves is to route the fluid to the desired actuator. Usually, these control valves comprise a spool located within a housing created either of steel or cast iron. The spool slides to different locations in the housing. Intersecting channels and grooves route the fluid based on the spool's position.

The spool is centrally positioned, help in place with springs. In this particular location, the supply fluid can be blocked and returned to the tank. When the spool is slid to one side, the hydraulic fluid is directed to an actuator and provides a return path from the actuator to tank. When the spool is transferred to the opposite side, the supply and return paths are switched. Once the spool is enabled to return to the center or neutral position, the actuator fluid paths become blocked, locking it into position.

Normally, directional control valves are made so as to be stackable. They normally have one valve per hydraulic cylinder and a fluid input which supplies all the valves inside the stack.

Tolerances are maintained extremely tightly, to be able to tackle the higher pressures and to prevent leaking. The spools will usually have a clearance within the housing no less than 25 Ã?â??Ã?µm or a thousandth of an inch. In order to prevent distorting the valve block and jamming the valve's extremely sensitive parts, the valve block would be mounted to the machine' frame by a 3-point pattern.

Mechanical levers, solenoids or a hydraulic pilot pressure might actuate or push the spool right or left. A seal allows a portion of the spool to protrude outside the housing where it is accessible to the actuator.

The main valve block is generally a stack of off the shelf directional control valves chosen by flow performance and capacity. Various valves are designed to be on-off, while some are designed to be proportional, like in flow rate proportional to valve position. The control valve is one of the most pricey and sensitive components of a hydraulic circuit.
